93702

Feature

• Material: steel, cold rolled
• Closing: soft-close
• Opening: full extension
• Traveling: one-way
• Screwing: side-mount with screws
• Color: zinc or black plated
• Packing: set or industrial
• Loading: 30 kg tested for 400 mm (16") length
• Material thickness (mm): 1.2/1.0/1.2
• Soft-closing distance: 42 mm
• Available length: 300-650 mm
